The first step was to work out how to tag them: the obvious choice being some kind of method-level designation (much as we have with the CommandMethod() attribute). So I thought it might be a good idea to populate a palette dynamically with buttons that call commands and methods that were somehow tagged in the current project.
#How to add tool palette in autocad 2015 software#
Want to learn more? Check out all the benefits of AutoCAD on our Features page troubleshoot and get the details on previous software versions over on the Autodesk Knowledge Network or take a look at all entries in our series, Exploring the Features and Benefits of AutoCAD.I needed to run some code from a modeless dialog, the other day, and found it was a bit of a pain to generate something quickly to do so. The Productivity Power of AutoCAD Tool Palettes – Revealed – AU 2015 Keep exploring Using AutoCAD’s Tool Palettes and the Design Center – YouTubeĪutoCAD Tool Palette Master Class – AU 2015 See the reference links below, to gain more knowledge and understanding on why tool palettes should be used within AutoCAD. Learning the core functions is just the beginning. Tool palettes give you a proverbial one-stop shop for commonly used features within AutoCAD. As you get more familiar with creating tool palettes, they can also be customized and grouped, giving you even more flexibility.įor many of us who use AutoCAD, the main objective is to produce accurate, precise drawings and models as quickly and efficiently as possible, and tool palettes are a great way to do just that.
As shown in the image below, simply go to the directory with your blocks, right-click, and choose create tool palette. When you have libraries of blocks that you have created, use the Design Center to create a tool palette in one step. One of the many benefits of tool palettes is how easy they are to create and organize. This allows you to customize blocks as you need to, but will not affect other users. However, the properties set in the tool palette do not affect the block itself. These options are held within each block property option. You can establish a set scale, prompt to rotate, explode, etc. For example, if a palette is created consisting of multiple types of pipe fittings, I can establish within the palette property to insert each fitting as a block or Xref. The main advantage with tool palette blocks are the property options. Instead of searching through multiple directories or libraries, you can create palettes and palette groups for each set of blocks. The most common use for tool palettes are blocks. This cuts down on how many clicks of the mouse you have to make, making you more productive. With tool palettes, create the pattern once, save it as a palette, and then drag and drop to other areas. For example, if you are hatching areas within a plan view and have multiple patterns and scales, you could run the hatch command and modify your settings each time you changed a pattern, adding many additional clicks to achieve what you need. Again, you can modify properties for each pattern. Whether you need a predefined pattern or gradient hatch, simply select the hatch pattern you want and drag inside the area you wish to hatch. Hatch patterns can also be saved as a palette.
You can even create flyout commands that combine multiple commands from one location, and manipulate properties (and even images) associated with commands. However, creating a tool palette of commands allows you to store some of you most commonly used commands in one location. Sure, there are many ways and locations to access commands: You can use the Command Window, ribbons, pull-down menus, the CUI dialog box, and more.
One type of tool palette is frequently used commands. Tool palettes can also be shared by exporting/importing to/by other users, and can be grouped like directories to provide you with even more flexibility and organization. As with other palettes, you can dock the tool palettes or have them float within your workspace or even another monitor. Tool palettes can consist of commonly used blocks, hatch patterns, and commands. AutoCAD comes with many default tool palette categories that can be expanded or customized, allowing you to create one for your own needs. Whether you prefer ribbons or toolbars, tool palettes provide the best of both worlds. In AutoCAD, tool palettes provide you with a combined method of accessing tools.
